Shock Absorber for 2021-2023 Ford F-150 2WD/4WD 0-2'' Rear Lift FOX

883-26-122 FOX Shock Absorber


Extended length, in. :28.37 Inch
Collapsed length, in. :17.4 Inch
Upper mount: Eyelet
Lower Mount: Eyelet
Shock Absorber; 2.5 Performance Series; Hydraulic/ Nitrogen Gas Charged; With Remote Reservoir; Limited 1 Year Warranty; Adjustable Valving; With Shock Boots; Zinc Plated; Set of 2
Attributes Type: Hydraulic/ Nitrogen Gas Charged With Coil Spring: No Adjustable Valving: Yes Extended Length (IN): 28.37 Inch Compressed Length (IN): 17.4 Inch Upper Mounting Style: Eyelet Lower Mounting Style: Eyelet Body Color: Gray Quantity: Set Of 2 Rod Diameter (IN): 7/8 Inch Valving Type: Application Specific Valving Ride Height Adjustable: Yes Rod Material: Steel Body Material: Aluminum With Reservoir: Yes Includes Dust Shield: No Includes Hardware: No Includes Boot: Yes Estimated Install Time (Hours): 1 FOX Performance Elite Series 2.5 shocks improve the stock 14th generation Ford F-150 platform by eliminating the vehicle’s forward rake, providing a level ride height, and increasing the suspension articulation of your truck. Type III anodization prevents corrosion and wear of the 2-1/2 Inch aluminum bodies. External reservoirs increase oil capacity, remove dead space from the shock body, and decrease the harshness associated with nitrogen ramp-up. Cooler shock temperatures, more travel, and consistent damping forces result. Each reservoir features a Dual Speed Compression (DSC) adjuster; strategically mounted to eliminate interference with aggressive tires at full lock. Quickly adapt your shocks for load, environment, and driving style using the DSC adjusters as the high-flow piston manages stability through all types of terrain. FOX shocks are designed and engineered to support the damping of your rig with the presumption that you’re engaged in various activities. Realize the potential of your F-150 on the next adventure. Performance Elite shocks provide the versatility required to navigate rough terrain and improve on-road manners while remaining comfortable and in control. Features & Benefits 2-1/2 Inch Impact Extruded And CNC Machined 6061-T6 Type III Anodized Aluminum Body Application-Specific Springs 7/8 Inch Hard Chrome-Plated Steel Shafts Vehicle-Specific Valving To Maximize Performance Redundant Sealing Pack System: Main Seal, Wiper Seal, Scraper Seal Rear Shaft Boot To Protect Against Roost Spray Limited 1 Year Warranty

https://vehiclepartimages.com/PMDT/FOX/InstallationInstructions/605-01-332-REV-A-COLOR.pdf
[Type: Hydraulic/ Nitrogen Gas Charged, With Coil Spring: No, Adjustable Valving: Yes, Extended Length (IN): 28.37 Inch, Compressed Length (IN): 17.4 Inch, Upper Mounting Style: Eyelet, Lower Mounting Style: Eyelet, Body Color: Gray, Quantity: Set Of 2, Rod Diameter (IN): 7/8 Inch, Valving Type: Application Specific Valving, Ride Height Adjustable: Yes, Rod Material: Steel, Body Material: Aluminum, With Reservoir: Yes, Includes Dust Shield: No, Includes Hardware: No, Includes Boot: Yes, Estimated Install Time (Hours): 1]
